EV XLPE

Cross Linked Polyethylene Wire For Electric Vehicles

Specifications

Nominal voltage: 1500V AC
Temperature range: -40~125℃
Standard: ISO6722

Product Description

New energy vehicles and equipment, energy storage equipment, medical devices, photovoltaics, robots, drones, etc.

Conductor			Insulation	Diameter (mm)	Max.cond Resistance (2/KM)	Unit Length (M/FT)
Cross Section (mm²)	Construction (No./mm)	Diameter (mm)	Nominal Thickness (mm)	Diameter (mm)	Max.cond Resistance (2/KM)	Unit Length (M/FT)
0.75	24/0.20	1.16	0.60	2.4+/-0.1	347	Rollable/axle type, as per customer's requirements
1.0	32/0.20	1.35	0.60	2.6+/-0.1	218
1.5	48/0.20	1.65	0.60	2.9+/-0.1	138
2.5	80/0.20	2.2	0.70	3.7+/-0.1	85.9
3.0	98/0.20	2.4	0.70	3.8+/-0.1	54.3
4.0	133/0.20	2.9	0.80	4.5+/-0.2	33.9
5.0	161/0.20	3.2	0.80	4.8+/-0.2	21.4
6.0	196/0.20	3.5	0.80	5.1+/-0.3	13.5
10.0	322/0.20	4.5	1.00	6.5+/-0.3	8.45
16.0	513/0.20	6.1	1.00	8.1+/-0.35	5.31
25.0	798/0.20	7.6	1.30	10.2+/-0.40	3.343
35.0	1121/0.20	8.9	1.30	11.5+/-0.40	2.652
50.0	1596/0.20	10.5	1.50	13.5+/-0.50	2.102
70.0	2242/0.20	12.3	1.50	15.3+/-0.50	1.323
95.0	3034/0.20	14.2	1.60	17.4+/-0.50	0.8315
120.0	3857/0.20	16	1.60	19.2+/-0.50	0.5231

FAQ

Q: How to choose the right wire for high-temperature environments?

A: For high-temperature environments, it is recommended to use fluoroplastic wires (e.g., UL1330, 200℃) or silicone rubber wires (e.g., UL3251, 250℃).
Q: Which wires are suitable for automotive or new energy vehicle internal wiring?

A: Wires for automotive electrical systems (e.g., QB-B, FLRY-A) and wires for electric vehicles (e.g., EV XLPE WIRE) are specifically designed for internal vehicle wiring.
Q: Which wire should be used for electronic equipment requiring anti-interference?

A: PVC sheathed wires with Al-Mylar shielding (e.g., UL2464, UL2517) can effectively resist external electromagnetic interference.
Q: Which wires have excellent oil and climate resistance?

A: Cross-linked PE wires (XLPE) and fluoroplastic wires (FEP) typically possess excellent oil and climate resistance due to their material properties.
Q: How to distinguish PVC electronic wires with different temperature ratings?

A: You can distinguish them by their UL style numbers, for example, UL1571 is rated for 80℃, while UL1015 is rated for 105℃.
